QPL9058

    0.5 - 6.0 GHz Ultra Low-Noise LNA

    Key Features

    • 0.5 - 6 GHz Operational Bandwidth
    • Ultra low noise figure, 0.59 dB NF @ 3.6 GHz
    • 36 dBm OIP3
    • 18 dB small signal gain
    • Bias adjustable for linearity optimization
    • Shut-down mode pin with 1.8V logic
    • Maintains OFF state with high Pin drive
    • Unconditionally stable

    The QPL9058 is a high-linearity, ultra-low noise amplifier in a small 2.0 x 2.0 mm surface-mount package. At 3.6 GHz, the amplifier typically provides 18 dB gain, +36 dBm OIP3 at a 55 mA bias setting, and 0.6 dB noise figure. The LNA can be biased from a single positive supply ranging from 3.3 to 5 volts. The device is housed in a green/RoHS-compliant industry-standard 2 x 2 mm package.

    The QPL9058 is bias adjustable and requires minimal external components to operate. It also has a power down control capability integrated into the die for TDD applications.

    Typical Applications

      • 5G mMIMO
      • Repeaters / DAS
      • Mobile Infrastructure
      • TDD / FDD System
      • General Purpose Wireless
      • LTE / WCDMA / CDMA / GSM
    Frequency Min(GHz) 0.5
    Frequency Max(GHz) 6
    Gain(dB) 18
    NF(dB) 0.6
    OP1dB(dBm) 20.5
    OIP3(dBm) 36
    Voltage(V) 5
    Current(mA) 55
    Package Type DFN
    Package(mm) 2.0 x 2.0
    RoHS Yes
    Lead Free Yes
    Halogen Free Yes
    ITAR Restricted No
    ECCN 5A991G
