QPF4516B
5 GHz 802.11ax Front End Module
Please contact Qorvo Sales for more information.
Key Features
- POUT = +17 dBm MCS11 HE160 -43 dB Dynamic EVM
- POUT = +20 dBm MCS9 VHT160 -40 dB Dynamic EVM
- POUT = +23 dBm MCS9 VHT80 -35 dB Dynamic EVM
- POUT = +24 dBm MCS7 HT20/40 -30 dB Dynamic EVM
- POUT = +27 dBm MCS0 HT20 Spectral Mask Compliance
- Optimized for +5 V Operation
- 33 dB Tx Gain
- 2 dB Noise Figure
- 15 dB Rx Gain & 6 dB Bypass Loss
- 30 dB 2.4 GHz Rejection on Rx Path
- Integrated Logarithmic Power Detector
| Mouser | 2434 | Buy Online > | |
| RELL | 0 | Buy Online > | |
| RFMW | 0 | Buy Online > |
The Qorvo® QPF4516B is an integrated front end module (FEM) designed for Wi-Fi 802.11ax systems. The compact form factor and integrated matching minimizes layout area in the application. Performance is focused on optimizing the PA for a 5 V supply voltage that conserves power consumption while maintaining the highest linear output power and leading edge throughput. Receive path matches the optimal technologies to maximize Rx sensitivity through noise figure performance that is consistent over a wider variety of conditions. The receive path is pinned out so external filtering can be added in the optimal position. Integrated die level filtering for 2nd and 3rd harmonics as well as 2.4 GHz rejection for DBDC operation are included.
A key feature is the intergration of a logarithmic power detector which enables power control across the entire power specturm for applications which use higher gain antennas or end users wanting to reduce device calibration time in production.
The QPF4516B integrates a 5 GHz power amplifier (PA), regulator, single pole two throw switch (SP2T), bypassable low noise amplifier (LNA) into a single device.
Typical Applications
- Access Points
- Wireless Routers
- Client Equipment
- Customer Premise Equipment
- Internet of Things
Product Categories
Application Categories
| Frequency Min(GHz) | 5.150 |
| Frequency Max(GHz) | 5.925 |
| Functionality | PA, Switch, LNA |
| Wi-Fi Standards | ax |
| Vcc(V) | 5 |
| 11ac Pout(dBm) | 23 |
| 11ac EVM(dB) | -35 |
| 11ac Current(mA) | 285 |
| 11n Pout(dBm) | 24 |
| 11n EVM(dB) | -30 |
| 11n Current(mA) | 305 |
| Tx Gain(dB) | 33 |
| OP1dB(dBm) | 31 |
| Rx Gain(dB) | 15 |
| NF(dB) | 2 |
| Bypass Loss(dB) | 6 |
| Rx Current(mA) | 23 |
| Package Type | Laminate |
| Package(mm) | 5.0 x 3.0 |
| RoHS | Yes |
| Lead Free | Yes |
| Halogen Free | Yes |
| ITAR Restricted | No |
| ECCN | 5A991G |
